ORIGINAL MATERIAL DESIGN

ORIGINAL TITANIUM MATERIAL

LIGHTWEIGHT
STRONG
DURABLE

Sourcing our own raw materials allows us to significantly improve quality whilst also keeping the price low. In addition, having complete control over the raw materials and manufacturing process is what allows us to produce high quality products at an affordable price.



DESIGN

TAIL PIPE

Made from Titanium material to Φ115mm diameter and 1mm thick piping. Straight cut designed and finished for race use. Finished off with the EXPREME Ti logo laser etched on the tip with the Titanium gradation blue colours.



CLAMP BAND

This clamp design is much stronger than the conventional flange and bolt type. It secures the pipe in place and can keep an airtight fixture whilst still being able to cope with the high heat, the stress loads and the vibrations that it will endure.





SILENCER

-SILENCER CASE-
This part is made from Titanium with the pipe size of φ152 and 1mm thickness. The oversized shell design optimizes exhaust gas flow which helps with power gains. Then with the embossed Tomei logo and beautiful heat gradation colouring gives it the finishing touch that you'd expect.




-PUNCHED MESH-
Made entirely from Titanium of 1mm thickness and with the open slot ratio of 32.6%. With the combination of light weight Titanium material, the high flow design delivers a really nice racing exhaust sound.




-GLASS WOOL-
The long fiber wool threads were adopted for the silencer. This type has proven to last longer than the traditional fiberglass materials even over a longer period of time with extensive high temperature exposure both at high and low pressures.




CONNECTING SPRINGS


The pipes are connected together with the use of the hook and spring design. This allows the pipe with some movement to help absorb vibrations. The hook springs alone is sufficient enough to hold the pipes together. However you will get the best secured pipe joints when using the clamp band and the springs together.





PRECISION WELDS

Titanium is known to be difficult to weld but with our experienced methods we are able to achieve the best results with strength, durability and quality in finish. With the use of the right equipment, attention to details to yeild the best results you would expect.




OUR HIGHLY SKILLED ENGINEERS, USE THE BEST ENVIRONMENT & PRODUCTION PROCESSES.



WELDING EQUIPEMENT

Using the gas lens optimizes shielding gas coverage which will ensure consistent, quality TIG welds.


STANDARD TYPE

Gases are discharged in a straight line. This method has a lower shielding effect.


GAS LENS

gus-lens.jpg This method discharges the gas over a wider area. The sealed effect is much higher this way.



WELDING JIG

Optimized back sealed jigs aids with quality design production. Strength is maintained even from the inside of the pipe.

※ WHY THE BACK SHEILDING IS NEEDED WITH THE AFTER SEAL
Titanium material is not easy to weld. So when the the weld reacts with the oxygen & nitrogen & hydrogen in the atmosphere at low temperatures, the weld will become brittle. Therefore it is vital to seal the gas off from the irregular atmospheric conditions. Welding will not work if the temperature behind the weld drops from 200 degrees celcius or less.




WELDING CONDITIONS

The welding procedure is performed with the best temperature controlled conditions. This helps secure the added strength and clean consistency in the quality of the welds. This prevents any defects that would have been caused by dust, wind and humidity.



PROCESS
Oil content, Cutting thorough the powder and the like removal of fat, You wash, prevent weld defect.





VARIOUS WELD CONDITIONS



(①Lens not used) The blue-gray is the color of the weld which shows that the weld has a problem.

(②Excessive Welding Current) The thin weld color is close to blue gray, this shows problems in the weld.

(③Excessive Welding Current) This will produce undesirable look.

(④ Without a back sheild) The white shows the oxidation, which means that the weld strength has decreased considerably.



Silver This is the sign of a perfect weld, free from any weld defects.
Gold/Blue A near perfect weld without any weld defects.
Purple/Blue Some signs of ductility on the weld surface. But, almost no influence in the metals quality characteristics.
Blue/Gray A considerable weld defect. The sheet welds ductility has considerably decrease.
White/Ash Yellow Bad condition, the weld is fragile.

※Above Note: The purplish blue colour is the sign that the weld is perfect.



With the above-mentioned result, "④Without back shield",
the weld actually looks fine. But only when you bend it is when you can see how weak it actually is.

When the surface conditions conditions are controlled well, the weld state will yield the best results (the presence of the back shield conditions differs) as shown in the photo, the weld still retains strength even after bending it to a full 180 degrees.
From the following points, ① appearance due to the colour of the welds, ② both are important, since it shows if the back has oxidized or not.
We pay extra attention to every details during the production process for our TOMEI products, when we use our jigs.




MUFFLER

Filtered by:

  • TYPE: WHOLE UNIT

  • Parts No.TB6070-NS01A
  • Weight49 lbs
  • MSRP$3,800.00
  • Dimension45 x 17 x 17 inch
  • Sub CategoryMUFFLER
  • Qty in Stock15
  • EngineNISSAN VR38DETT
  • NoteIn Stock Now!
  • ModelNISSAN 35 GT-R
  • Available Repair PartsYes
  • Parts No.TB6070-NS01A
  • MSRP$3,800.00
  • Sub CategoryMUFFLER
  • EngineNISSAN VR38DETT
  • ModelNISSAN 35 GT-R
  • Weight49 lbs
  • Dimension45 x 17 x 17 inch
  • Qty in Stock15
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-FR01A
  • Weight25 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock23
  • EngineFORD MUSTANG ECOBOOST
  • NoteIn Stock Now!
  • ModelFORD MUSTANG ECOBOOST
  • Available Repair PartsYes
  • Parts No.TB6090-FR01A
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineFORD MUSTANG ECOBOOST
  • ModelFORD MUSTANG ECOBOOST
  • Weight25 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock23
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-FR02A
  • Weight30 lbs
  • MSRP$1,590.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock21
  • EngineFORD FOCUS ST
  • NoteIn Stock Now!
  • ModelFORD FOCUS ST
  • Available Repair PartsYes
  • Parts No.TB6090-FR02A
  • MSRP$1,590.00
  • Sub CategoryMUFFLER
  • EngineFORD FOCUS ST
  • ModelFORD FOCUS ST
  • Weight30 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock21
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-HN04A
  • Weight21 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock16
  • EngineHONDA F20C, HONDA F22C
  • NoteIn Stock Now!
  • ModelHONDA S2000
  • Available Repair PartsYes
  • Parts No.TB6090-HN04A
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineHONDA F20C, HONDA F22C
  • ModelHONDA S2000
  • Weight21 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock16
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-HN06A
  • Weight26 lbs
  • MSRP$1,390.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock13
  • EngineHONDA K20C
  • NoteIn Stock Now!
  • ModelHONDA FK CIVIC TYPE-R
  • Available Repair PartsYes
  • Parts No.TB6090-HN06A
  • MSRP$1,390.00
  • Sub CategoryMUFFLER
  • EngineHONDA K20C
  • ModelHONDA FK CIVIC TYPE-R
  • Weight26 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock13
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-HN06B
  • Weight29 lbs
  • MSRP$1,390.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock6
  • EngineHONDA K20C
  • NoteIn Stock Now!
  • ModelHONDA FK CIVIC TYPE-R
  • Available Repair PartsYes
  • Parts No.TB6090-HN06B
  • MSRP$1,390.00
  • Sub CategoryMUFFLER
  • EngineHONDA K20C
  • ModelHONDA FK CIVIC TYPE-R
  • Weight29 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock6
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-HN06C
  • Weight36 lbs
  • MSRP$1,890.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock21
  • EngineHONDA K20C
  • NoteIn Stock Now!
  • ModelHONDA FK CIVIC TYPE-R
  • Available Repair PartsYes
  • Parts No.TB6090-HN06C
  • MSRP$1,890.00
  • Sub CategoryMUFFLER
  • EngineHONDA K20C
  • ModelHONDA FK CIVIC TYPE-R
  • Weight36 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock21
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-HN06D
  • Weight25 lbs
  • MSRP$1,390.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock0
  • EngineHONDA K20C
  • NoteETA:4/30/2024
  • ModelHONDA FL5 CIVIC TYPE-R
  • Available Repair PartsYes
  • Parts No.TB6090-HN06D
  • MSRP$1,390.00
  • Sub CategoryMUFFLER
  • EngineHONDA K20C
  • ModelHONDA FL5 CIVIC TYPE-R
  • Weight25 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock0
  • NoteETA:4/30/2024
  • Available Repair PartsYes
  • New

  • Parts No.TB6090-HN06E
  • Weight35 lbs
  • MSRP$1,890.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock0
  • EngineHONDA K20C
  • NoteETA:4/30/2024
  • ModelHONDA FL5 CIVIC TYPE-R
  • Available Repair PartsYes
  • Parts No.TB6090-HN06E
  • MSRP$1,890.00
  • Sub CategoryMUFFLER
  • EngineHONDA K20C
  • ModelHONDA FL5 CIVIC TYPE-R
  • Weight35 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock0
  • NoteETA:4/30/2024
  • Available Repair PartsYes
  • New

  • Parts No.TB6090-HY01A
  • Weight23 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock17
  • EngineHYUNDAI G4KF
  • NoteIn Stock Now!
  • ModelHYUNDAI GENESIS COUPE 2.0T
  • Available Repair PartsYes
  • Parts No.TB6090-HY01A
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineHYUNDAI G4KF
  • ModelHYUNDAI GENESIS COUPE 2.0T
  • Weight23 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock17
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-MT01A
  • Weight24 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock27
  • EngineMITSUBISHI 4G63
  • NoteIn Stock Now!
  • ModelMITSUBISHI EVO7-9
  • Available Repair PartsYes
  • Parts No.TB6090-MT01A
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineMITSUBISHI 4G63
  • ModelMITSUBISHI EVO7-9
  • Weight24 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock27
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-MT01B
  • Weight23 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock23
  • EngineMITSUBISHI 4G63
  • NoteIn Stock Now!
  • ModelMITSUBISHI EVO8-9
  • Available Repair PartsYes
  • Parts No.TB6090-MT01B
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineMITSUBISHI 4G63
  • ModelMITSUBISHI EVO8-9
  • Weight23 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock23
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-MT02A
  • Weight22 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock34
  • EngineMITSUBISHI 4B11
  • NoteIn Stock Now!
  • ModelMITSUBISHI EVO10
  • Available Repair PartsYes
  • Parts No.TB6090-MT02A
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineMITSUBISHI 4B11
  • ModelMITSUBISHI EVO10
  • Weight22 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock34
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-MZ01A
  • Weight25 lbs
  • MSRP$1,190.00
  • Dimension44 x 20 x 9 inch
  • Sub CategoryMUFFLER
  • Qty in Stock18
  • EngineMAZDA B6-ZE, MAZDA BP-ZE
  • NoteIn Stock Now!
  • ModelMAZDA NA MX-5 MIATA
  • Available Repair PartsYes
  • Parts No.TB6090-MZ01A
  • MSRP$1,190.00
  • Sub CategoryMUFFLER
  • EngineMAZDA B6-ZE, MAZDA BP-ZE
  • ModelMAZDA NA MX-5 MIATA
  • Weight25 lbs
  • Dimension44 x 20 x 9 inch
  • Qty in Stock18
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-MZ02A
  • Weight22 lbs
  • MSRP$990.00
  • Dimension44 x 20 x 9 inch
  • Sub CategoryMUFFLER
  • Qty in Stock22
  • EngineMAZDA B6-ZE, MAZDA BP-ZE, MAZDA BP-VE
  • NoteIn Stock Now!
  • ModelMAZDA NB MX-5 MIATA
  • Available Repair PartsYes
  • Parts No.TB6090-MZ02A
  • MSRP$990.00
  • Sub CategoryMUFFLER
  • EngineMAZDA B6-ZE, MAZDA BP-ZE, MAZDA BP-VE
  • ModelMAZDA NB MX-5 MIATA
  • Weight22 lbs
  • Dimension44 x 20 x 9 inch
  • Qty in Stock22
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-MZ03A
  • Weight11 lbs
  • MSRP$590.00
  • Dimension36 x 12 x 8 inch
  • Sub CategoryMUFFLER
  • Qty in Stock15
  • EngineMAZDA LF-VE
  • NoteIn Stock Now!
  • ModelMAZDA NC MX-5 MIATA
  • Available Repair PartsYes
  • Parts No.TB6090-MZ03A
  • MSRP$590.00
  • Sub CategoryMUFFLER
  • EngineMAZDA LF-VE
  • ModelMAZDA NC MX-5 MIATA
  • Weight11 lbs
  • Dimension36 x 12 x 8 inch
  • Qty in Stock15
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-MZ05A
  • Weight20 lbs
  • MSRP$990.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock21
  • EngineMAZDA 13B-REW
  • NoteIn Stock Now!
  • ModelMAZDA FD RX-7
  • Available Repair PartsYes
  • Parts No.TB6090-MZ05A
  • MSRP$990.00
  • Sub CategoryMUFFLER
  • EngineMAZDA 13B-REW
  • ModelMAZDA FD RX-7
  • Weight20 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock21
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-MZ06A
  • Weight22 lbs
  • MSRP$990.00
  • Dimension44 x 20 x 9 inch
  • Sub CategoryMUFFLER
  • Qty in Stock39
  • EngineMAZDA PE-VPR, MAZDA P5-VP
  • NoteIn Stock Now!
  • ModelMAZDA ND MX-5 MIATA
  • Available Repair PartsYes
  • Parts No.TB6090-MZ06A
  • MSRP$990.00
  • Sub CategoryMUFFLER
  • EngineMAZDA PE-VPR, MAZDA P5-VP
  • ModelMAZDA ND MX-5 MIATA
  • Weight22 lbs
  • Dimension44 x 20 x 9 inch
  • Qty in Stock39
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-NS02A
  • Weight25 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock56
  • EngineNISSAN VQ37VHR
  • NoteIn Stock Now!
  • ModelNISSAN 370Z
  • Available Repair PartsYes
  • Parts No.TB6090-NS02A
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineNISSAN VQ37VHR
  • ModelNISSAN 370Z
  • Weight25 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock56
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-NS04A
  • Weight25 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock39
  • EngineNISSAN VQ35DE
  • NoteIn Stock Now!
  • ModelNISSAN 350Z
  • Available Repair PartsYes
  • Parts No.TB6090-NS04A
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineNISSAN VQ35DE
  • ModelNISSAN 350Z
  • Weight25 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock39
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-NS04G
  • Weight25 lbs
  • MSRP$1,390.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock29
  • EngineNISSAN VQ35DE
  • NoteIn Stock Now!
  • ModelINFINITI G35 COUPE, NISSAN SKYLINE V35 COUPE
  • Available Repair PartsYes
  • Parts No.TB6090-NS04G
  • MSRP$1,390.00
  • Sub CategoryMUFFLER
  • EngineNISSAN VQ35DE
  • ModelINFINITI G35 COUPE, NISSAN SKYLINE V35 COUPE
  • Weight25 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock29
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-NS05A
  • Weight26 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock32
  • EngineNISSAN RB26DETT
  • NoteIn Stock Now!
  • ModelNISSAN 32 GT-R
  • Available Repair PartsYes
  • Parts No.TB6090-NS05A
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineNISSAN RB26DETT
  • ModelNISSAN 32 GT-R
  • Weight26 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock32
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-NS05B
  • Weight26 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock20
  • EngineNISSAN RB26DETT
  • NoteIn Stock Now!
  • ModelNISSAN 33 GT-R
  • Available Repair PartsYes
  • Parts No.TB6090-NS05B
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineNISSAN RB26DETT
  • ModelNISSAN 33 GT-R
  • Weight26 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock20
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-NS05C
  • Weight26 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock13
  • EngineNISSAN RB26DETT
  • NoteIn Stock Now!
  • ModelNISSAN 34 GT-R
  • Available Repair PartsYes
  • Parts No.TB6090-NS05C
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineNISSAN RB26DETT
  • ModelNISSAN 34 GT-R
  • Weight26 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock13
  • NoteIn Stock Now!
  • Available Repair PartsYes

  • Parts No.TB6090-NS06A
  • Weight28 lbs
  • MSRP$1,290.00
  • Dimension51 x 11 x 16 inch
  • Sub CategoryMUFFLER
  • Qty in Stock18
  • EngineNISSAN RB25DET NEO6
  • NoteIn Stock Now!
  • ModelNISSAN 34 SKYLINE
  • Available Repair PartsYes
  • Parts No.TB6090-NS06A
  • MSRP$1,290.00
  • Sub CategoryMUFFLER
  • EngineNISSAN RB25DET NEO6
  • ModelNISSAN 34 SKYLINE
  • Weight28 lbs
  • Dimension51 x 11 x 16 inch
  • Qty in Stock18
  • NoteIn Stock Now!
  • Available Repair PartsYes
